DP-HXP26/28/30 hydraulic-driven polyurea sprayer equipment
The Heavy-Duty Hydraulic Polyurea Spraying Machine offers 21kW, 26kW, and 28kW power options for enhanced capacity and efficiency. Designed for professional contractors, it ensures faster, high-quality polyurea applications. A must-have for everyday use.
| Item No. | HXP26 | HXP28 | HXP30 |
| Voltage / phase | 380v 50/60hz- 3ph | 380v 50/60hz- 3ph | 380v 50/60hz- 3ph |
| Total power | 21KW (Motor 4500W Main heater 6000W*2 Heating hose 3500W Others 1000W) |
26KW (Motor 5500W Main heater 8000W*2 Heating hose 3500W Others 1000W) |
28KW (Motor 5500W Main heater 9000W*2 Heating hose 3500W Others 1000W) |
| Driven | Hydraulic-driven | Hydraulic-driven | Hydraulic-driven |
| Air Supply | 0.6~0.8MPa 1m³/min | 0.6~0.8MPa 1m³/min | 0.6~0.8MPa 1m³/min |
| Viscosity range | 200~1000CPS | 200~1000CPS | 200~1000CPS |
| Application | Polyurethane & Polyurea | Polyurethane & Polyurea | Polyurethane & Polyurea |
| Mixing ratio | 1:1 | 1:1 | 1:1 |
| Max. pressure | 300bar/4350psi | 350bar/5075psi | 350bar/5075psi |
| Output volume | 2~12Kg/min | 2~14Kg/min | 2~15Kg/min |
| Max. hose length | 105M | 120M | 120M |
| Heating temperature | 0~80 ℃ | 0~80 ℃ | 0~80 ℃ |
| Net & Gross weight | 216/350kgs | 350/450kgs | 357/500kgs |
| Dimensions | 120X90X155cm | 120X90X155cm | 120X90X155cm |
| Contents in package | Machine 1set, (TP3)10:1 transfer pump 2sets, Heating hose 15m, Heating whip hose 3M*2pcs, Self-cleaning spray gun 1 set, Repair kit 1set, Cleaning fluid, DOP 1kg | Machine 1set, (TP3)10:1 transfer pump 2sets, Heating hose 15m, Heating whip hose 3M*2pcs, Self-cleaning spray gun 1 set, Repair kit 1set, Cleaning fluid, DOP 1kg | Machine 1set, (TP3)10:1 transfer pump 2sets, Heating hose 15m, Heating whip hose 3M*2pcs, Self-cleaning spray gun 1 set, Repair kit 1set, Cleaning fluid, DOP 1kg |
DP-HXP30 Polyurea Sprayer equipment, simirlar to H-XP3, is designed for
professional polyurea spraying (or polyurethane spraying) that requires high pressure, and this is always the top no. 1 option for professional contractors/painters.
The polyurea spraying machine is hydraulic-driven power system with the best performance,superior power and high volume output, etc.
Model No.: DP-HXP30
Mode of driving: Hydraulic-driven
Mixing Volumetric Ratio: 1:1
Maximum Output Volume: 2.8gpm/10.6lpm
Real Air consumption: 0.4CBM/MIN
air compressor output: 0.6CBM/min
Spraying materials: about 200 square meters per hour
Maximum temperature: 88°C (190°F)
Working temperature: 70-75°C
Maximum pressure: 240bar / 3490psi
Working pressure: 180-200bar / 2600-2900psi
Heater power: 20.4kw
Maximum hose length: 125m/410ft
Power: 3-phase 400V/50Hz 52A
Net weight: 271kgs
Overall size: 95cm x 98cm x 120cm
Packing dimension: 105cm x 108cm x 130cm
Contents in Package:
Polyurea spraying machine 1 set, Transfer Pump 2 sets, Heating Hose 15m (50ft) 2500watt,
Heating Whip Hose 1.5m (5ft), Polyurea Spray Gun 1 set,
Repair Kit 1 set, Cleaning Fluid 1 kg, DOP 1 kg,
