DP-6870 7L Heavy-duty paint spray equipment

1. Powerful Induction Motor

• Motor Specifications: Equipped with a 2.2 kW (3 HP) induction motor, ensuring reliable and robust power for extensive applications.
• Brushless Design: Features a brushless motor that minimizes maintenance and eliminates carbon brush wear and sparks.

2. Professional-Grade Performance

• Target Users: Designed for professional painters, making it suitable for residential and commercial projects alike.
• Versatility: Ideal for both interior and exterior applications, accommodating various coating types.

3. Key Specifications

• Model Number: DP6860
• Type: Electric & Diaphragm
• Pressure Control: Mechanical pressure control for consistent performance.
• Max Flow Rate: 6.0 L/min, allowing for efficient and rapid application.
• Max Pressure: 220 bar (3200 psi) for exceptional atomization and coverage.
• Max Tip Size: Supports up to a 0.035″ tip size, enhancing efficiency and reducing painting job time.

4. Hose Compatibility

• Standard Hose Length: Comes with a 15-meter hose for versatile applications.
• Maximum Hose Length: Supports up to 90 meters of hose, providing flexibility for larger job sites.

5. Paint Viscosity

• Versatile Use: Capable of handling medium to high viscosity paints, ensuring compatibility with a wide range of coatings.

6. Spare Parts for Easy Maintenance

• Included Spare Parts: Designed for easy repairs and maintenance, the following parts are included:
  • Diaphragm
  • Outlet valve
  • Inlet valve
  • Airless tip, tip gasket, tip guard, and filter.

7. Enhanced Output Capacity

• Design Features:
  • Large size inlet and outlet valves.
  • Oversized diaphragm to generate a high output volume per minute.
• Efficiency: The capability to support maximum tip sizes ensures faster application and greater efficiency on the job.

8. Ideal for Big Contractors

• Target Audience: Perfectly suited for large contractors and professional painters who require high-performance equipment for extensive projects.
