DP-9600EL Electric belt driven hydraulic airless paint sprayer with compact frame

Features of DP-9600EL Hydraulic Airless High-Pressure Spraying Unit (Belt driven ):

The hydraulic paint spraying equipment use only mechanical components which is powered by hydraulic oil, so it means no PCB board error or broken, it will save your repairing cost after years of spraying.

Powerful high-performance pump -the power pack for large building projects and applying high viscosity materials.
The material pump of the Heavy duty units is driven by hydraulic motor which is imported from Japan (Taiwan hydraulic motor is available with cheaper price).
This has advantage that the shovel piston has a distinctly longer and slower stroke than with direct drive electric pumps.
Our own improved bigger oil tank which contains of 13L hydraulic oil inside, much bigger than Wagner original machine which is only 5L. The more oil inside, the less temperature machine is operating, and less wearing for the spare parts.
The low wear rate and the equipment are further positive aspects of hydraulic technology.
The wear surfaces of cylinder and piston rod are coated with an extremely wear resistant layer of hard chrome, making them able to with-stand aggressive and abrasive materials.
The pressure can be smoothly regulated up to 230 bar for perfect matching.

Applications of hydraulic airless sprayer (electric powered):

Indoors :
Large interior wall surfaces requiring a high level of productivity and surfaces coverage power:e.g. Primers, latex paints, emulsions and all other water diluted and solvent based materials
Applications of fillers (airless spray fillers)
Flame proofing / fireproofing, putty / plaster, gypsum,

Outdoors :
Exterior wall surfaces
Roof coatings
Thick coating materials
Bituminous paints
Corrosion proofing
Inorganic zinc and micaceous iron paints basement sealants.

Other :
– Fabric and other adhesives

– epoxy paint

– polyurethane paint
